Yamaha Grizzly EPS XT-R
Yamaha Grizzly EPS XT-R
General Information
Manufacturer
Yamaha
Model Year
2025
Model
Grizzly EPS XT-R
Model Code
YFM70GPZSB
Color
Matte Grey / Metallic Black
Brakes/Wheels/Tires
Brakes
Front / Rear – Dual hydraulic disc
Tires
Front / Rear – AT27 x 10-14 Maxxis® ‘Zilla MU01
Dimensions
Length
81.5 in.
Height
50 in.
Width
49.2 in.
Weight
Wet – 783 lb. (Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.)
Ground Clearance
Maximum – 11.8 in.
Wheelbase
49.2 in.
Seat Height
36.6 in.
Drivetrain
Transmission
Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
Drive System
4×4
Drive
Final – On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft
Engine
Engine
SOHC 4-stroke
Cooling
Liquid
Displacement
686 cc
Bore x Stroke
4 x 3.3 in. (102 x 84 mm)
Compression Ratio
10.0:1
Fuel System
Yamaha Fuel Injection (YFI), 44 mm
Fuel Capacity
4.8 gal.
Operational
Suspension
Front – Independent double wishbone; 5-way preload adjustment
Front travel – 7.6 in.
Rear – Independent double wishbone with anti-sway bar; 5-way preload adjustment
Rear travel – 9.1 in.
